Let’s Learn About Auto-Instrumentation with the OTel Operator!
So, you’re new to auto-instrumentation with the OTel Operator. You’ve just taken your first stab at auto-instrumenting your app using the Operator’s Instrumentation custom resource (CR). You’ve added an auto-instrumentation annotation to your service. But…IT’S. NOT. WORKING! WHYYYY??? 💀
Don’t panic, my friend! I’ve totally been there, and today, I will share some tips on how to troubleshoot auto-instrumentation with the OTel Operator.
⚠️ NOTE: In this blog post, when I refer to a “service”, it’s synonymous with application definition, which at a bare minimum includes a
Deploymentand aService.⚠️ NOTE: This is not a full-fledged tutorial on auto-instrumentation with the OTel Operator.
OTel Operator Auto-Instrumentation Primer
When you auto-instrument your application using the OTel Operator, you need to:
- Install the OTel Operator in your Kubernetes cluster.
- Install an OTel Collector. This is done via the OTel Operator’s
OpenTelemetryCollectorcustom resource. - Configure auto-instrumentation via the
Instrumentationcustom resource. - Tell your service to use the auto-instrumentation.
🚨NOTE: The OTel Collector is totally optional, since you can send instrumentation directly from your application to your Observability back-end; however, using a Collector is highly recommended for production.
Instrumentation Custom Resource
The Instrumentation CR is used by the OTel Operator to manage auto-instrumentation. Below is an example of a very basic and stripped downInstrumentation resource definition, but it gets the job done!
If you want to get fancy, you can configure additional things like OTel environment variables, and even language-specific OTel environment variables (e.g. Python). If you’re looking for an example of what that might look at check out this example.
The Instrumentation resource defines and configures auto-instrumentation; however, your service won’t know about the auto-instrumentation until tell it, by using a special auto-instrumentation annotation.
Auto-instrumentation Deployment annotation
The basic auto-instrumentation annotation looks like this:
annotations:
instrumentation.opentelemetry.io/inject-python: "true"The above line says, “Inject Python auto-instrumentation into this service.”
You can also get a bit fancier, too! For example:
annotations:
instrumentation.opentelemetry.io/inject-python: "my-instrumentation"The above says, “Inject Python auto-instrumentation into this service, based on the configuration from an Instrumentation resource named my-instrumentation located in the service’s namespace.
And if you want to get really fancy:
annotations:
instrumentation.opentelemetry.io/inject-python: "my-other-namespace/my-instrumentation"The above says, “Inject Python auto-instrumentation into this service, based on the configuration from an Instrumentation resource named my-instrumentation located in the namespace my-other-namespace.
That’s all well and good, but where does the auto-instrumentation annotation go? It resides under spec.template.metadata.annotations of the service’s Deployment definition, like in the one below. Note the auto-instrumentation annotation in lines 20-21.
Gotchas & Troubleshooting Tips
Seems pretty straightforward, right? You’ve defined your Instrumentation resource, and you’ve annotated your service. Woo! You excitedly look for your traces and then…WHERE. ARE. THE. TRACES?? 😱
Never fear! Let’s do some troubleshooting.
1- Did the Instrumentation resource install?
After installing the Instrumentation resource, let’s make sure that it actually installed correctly by running this command:
kubectl describe otelinst -n <namespace>Where <namespace> is the namespace in which the Instrumentation resource is deployed.
If everything looks good, your output should look something like this:
Name: python-instrumentation
Namespace: application
Labels: app.kubernetes.io/managed-by=opentelemetry-operator
Annotations: instrumentation.opentelemetry.io/default-auto-instrumentation-apache-httpd-image:
ghcr.io/open-telemetry/opentelemetry-operator/autoinstrumentation-apache-httpd:1.0.3
instrumentation.opentelemetry.io/default-auto-instrumentation-dotnet-image:
ghcr.io/open-telemetry/opentelemetry-operator/autoinstrumentation-dotnet:0.7.0
instrumentation.opentelemetry.io/default-auto-instrumentation-go-image:
ghcr.io/open-telemetry/opentelemetry-go-instrumentation/autoinstrumentation-go:v0.2.1-alpha
instrumentation.opentelemetry.io/default-auto-instrumentation-java-image:
ghcr.io/open-telemetry/opentelemetry-operator/autoinstrumentation-java:1.26.0
instrumentation.opentelemetry.io/default-auto-instrumentation-nodejs-image:
ghcr.io/open-telemetry/opentelemetry-operator/autoinstrumentation-nodejs:0.40.0
instrumentation.opentelemetry.io/default-auto-instrumentation-python-image:
ghcr.io/open-telemetry/opentelemetry-operator/autoinstrumentation-python:0.39b0
API Version: opentelemetry.io/v1alpha1
Kind: Instrumentation
Metadata:
Creation Timestamp: 2023-07-28T03:42:12Z
Generation: 1
Resource Version: 3385
UID: 646661d5-a8fc-4b64-80b7-8587c9865f53
Spec:
...
Exporter:
Endpoint: http://otel-collector-collector.opentelemetry.svc.cluster.local:4318
...
Propagators:
tracecontext
baggage
Python:
Image: ghcr.io/open-telemetry/opentelemetry-operator/autoinstrumentation-python:0.39b0
Resource Requirements:
Limits:
Cpu: 500m
Memory: 32Mi
Requests:
Cpu: 50m
Memory: 32Mi
Resource:
Sampler:
Events: <none>2- Do the OTel Operator logs have any auto-instrumentation errors?
How do the OTel Operator logs look? Anything fishy? To check the logs, run this command:
kubectl logs -l app.kubernetes.io/name=opentelemetry-operator --container manager -n opentelemetry-operator-system --followIf everything looks good, you shouldn’t see any errors related to auto-instrumentation.
3- Did you deploy things in the right order?
Order matters! You need to deploy your Instrumentation resource before you deploy your service, otherwise, the auto-instrumentation won’t work! Why?
Recall our auto-instrumentation annotation:
annotations:
instrumentation.opentelemetry.io/inject-python: "true"The above tells the OTel Operator to look for an Instrumentation object in the pod’s namespace. It also tells the Operator to inject Python auto-instrumentation into the pod.
When the pod starts up, the annotation tells the Operator to look for an Instrumentation object in the pod’s namespace, and to inject Python auto-istrumentation into the pod. It adds an init-container to the application’s pod, called opentelemetry-auto-instrumentation, which is then used to injects the auto-instrumentation into the app container.
But if the Instrumentation resource isn’t present by the time your service is deployed, the init-container can’t be created. So if you deploy your service before you deploy your Instrumentation resource, the instrumentation will fail.
To make sure that the opentelemetry-auto-instrumentation init-container has started up correctly (or has even started up at all), run the following command:
kubectl get events -n <your_app_namespace>If all goes well, then you should see entries that include something like this:
53s Normal Created pod/py-otel-server-7f54bf4cbc-p8wmj Created container opentelemetry-auto-instrumentation
53s Normal Started pod/py-otel-server-7f54bf4cbc-p8wmj Started container opentelemetry-auto-instrumentationIf your output is missing Created and/or Started entries for opentelemetry-auto-instrumentation, then it means that there is an issue with your auto-instrumentation. This can be the result of any of the following:
- The
Instrumentationresource wasn’t installed (or wasn’t installed properly). - The
Instrumentationresource was installed after the application was deployed. - There’s an error in the auto-instrumentation annotation, or the annotation in the wrong spot — see #4 below.
You might also want to check the output of the events command for any errors, as these might help point to your issue.
4- Is the auto-instrumentation annotation correct?
Okay, you’ve added the auto-instrumentation annotation, but did you do it correctly? Here are a couple of things to check for:
- Are you auto-instrumenting for the right language? In a classic case of copy-pasta, I once tried to auto-instrument a Python application by adding a Javascript auto-instrumentation annotation. 🫠🫠🫠
- Did you put the auto-instrumentation annotation in the right spot? When you’re defining a
Deployment, there are two spots where you could add annotations:spec.metadata.annotations, andspec.template.metadata.annotations. The auto-instrumentation annotation needs to be added tospec.template.metadata.annotations, otherwise it won’t work.
5- Did you configure your auto-instrumentation endpoint properly?
The Instrumentation resource has a spot where you can define the destination for your telemetry data: spec.exporter.endpoint (see lines 6–8 in the Instrumentation resource exmaple above). If you leave that out, it defaults to http://localhost:4317. Unfortunately, that won’t send your output anywhere useful.
If you’re sending out your instrumentation to an OTel Collector (again…highly recommended that you do so in Production), the value of spec.exporter.endpoint should reference the name of your OTel Collector Service. If you look at the Instrumentation example above (lines 6–8), the Collector endpoint is set to http://otel-collector.opentelemetry.svc.cluster.local:4318.
Where otel-collector is the name of the OTel Collector Kubernetes Service. And because the Collector is running in a different namespace from our application, we must also append opentelemetry.svc.cluster.local to the Collector’s service name, where opentelemetry is the namespace in which our Collector resides.
If everything appears to be correct in you endpoint definition, there’s one more thing that you should probably look at: are you using the right Collector port? You see, it turns out that you can’t use gRPC with Python auto-instrumentation. This means that the OTel Collector port must be set to 4318 (HTTP) instead of 4317 (gRPC).
Final Thoughts
The OTel Operator’s auto-instrumentation capability may seem intimidating at first glance, but if you understand the basic concepts, what’s going on behind the scenes, and what to look for when troubleshooting your auto-instrumentation, it’s not so scary! In fact, auto-instrumentation via the OTel Operator is pretty damn cool, if I do say so myself. I was definitely pleasantly surprised. 😀
I have to admit that the OTel Operator docs on Auto-Instrumentation were a bit confusing at times, and had no troubleshooting guidance, so after writing this blog post, I also wanted to make sure that the docs were a bit clearer for newbs such as myself. Check out my PR to update the docs. I encourage y’all to do the same. If the docs aren’t clear, whether it’s for OTel or some other open source project, make sure that you contribute to them, so that they benefit the entire community! 🌈
I hope y’all learned something new and cool with this! There’s obviously a LOT more to dig into on this topic, but hopefully this gives you enough of a starting point for auto-instrumentation with the OTel Operator. If you’d like to learn more about the OTel Operator, you should check out #otel-operator channel in the CNCF Slack. The folks on there are super helpful and responsive.
Now, please enjoy this photo of my rat Phoebe, getting some lunchtime cuddles from my husband.
Until next time, peace, love, and code! ✌️💜👩💻
